We supply the commercial mild hyperbaric chamber for hotels, resorts, recovery studios, gyms, and corporate wellness spaces, direct from the factory. Whether you are opening a recovery studio, adding a service to a gym, fitting out a hotel spa, or specifying chambers for a wellness project, we supply the equipment, the configuration advice, and the documentation to get it installed and running.
The same equipment serves very different commercial settings. The main differences are floor space, expected throughput, and how premium the experience needs to feel.
Purpose-built spaces combining chamber sessions with sauna, cold plunge, and massage. Often the anchor service of the whole business.
Adding a recovery tier to an existing membership offer, with more margin per square meter than another training zone.
A premium in-house wellness amenity that differentiates the property.
A signature service that expands the menu beyond beauty treatments.
A comfortable, non-clinical recovery option within a broader wellness program.
Amenities for corporate wellness suites, high-end residential buildings, and private clubs.
A commercial purchase involves more than picking a model. We support the parts of the process that usually cause delays.
Send your room dimensions and expected throughput, and we recommend the model, quantity, and layout, including whether one large chamber or two smaller units serves you better.
Detailed product specifications for architects, contractors, or interior designers.
Exterior, colors, finish, and logo customized to your interior and identity.
HS codes, complete shipping documentation, and FOB or DDP terms, with export packaging built for long-distance transport.
Guidance on floor space, power, ventilation, and staff workflow before delivery.
A modular oxygen system means components can be replaced independently, keeping maintenance simple and downtime short.
A quick reference for the most common commercial configurations.
| Project type | Typical configuration | Considerations |
|---|---|---|
| Small studio, boutique | 1 × Sitting HS050 | Lowest capital outlay; validate demand before expanding |
| Full-service gym | 1–2 × Sit-and-Lie HC050 | Flexible posture serves a mixed membership base |
| Premium spa or retreat | 1 × Lying HL050 (M or L) | Comfort-led experience for higher price points |
| Flagship or high-traffic center | 1–2 × Hard shell | Durable structure and strong visual presence for heavy use |
| Hotel or multi-room project | Mixed range across locations | Standardize on one model family for simpler servicing |
| Model | Posture | Chamber size | Pressure | Oxygen output |
|---|---|---|---|---|
| Sitting Mild Hyperbaric Chamber HS050 | Seated | 1600 × 650 × 1200 mm 63.0 × 25.6 × 47.2 in |
1.3 ATA | 5 L/min, 93 ± 3% |
| Sitting & Lying Mild Hyperbaric Chamber HC050 | Seated or lying | 2000 × 650 × 1200 mm 78.7 × 25.6 × 47.2 in |
1.3 ATA | 5 L/min, 93 ± 3% |
| Lying Mild Hyperbaric Chamber HL050 (M) | Full-length lying | Ø 750 × L 2000 mm Ø 29.5 × L 78.7 in |
1.3 ATA | 5 L/min, 93 ± 3% |
| Lying Mild Hyperbaric Chamber HL050 (L) | Full-length lying | Ø 800 × L 2250 mm Ø 31.5 × L 88.6 in |
1.3 ATA | 5 L/min, 93 ± 3% |
Standard soft-shell configurations run at about 1.3 ATA. A 1.5 ATA working pressure is available only as a built-to-order custom configuration and is confirmed in writing before production.
The planning zone adds a 350 mm (13.8 in) walkway along the open side and at the foot end, a 420 mm (16.5 in) bay for the oxygen concentrator and air dryer (stacked, 420 × 250 mm / 16.5 × 9.8 in each), and a 100 mm (3.9 in) heat-dissipation gap at the wall end, per unit. Multiply and adjust for multi-unit rooms, and keep a wall power outlet behind each equipment set, not a door.
| Model | Chamber footprint | Installed footprint (chamber + equipment + heat gap) | Planning zone area (+350 mm / 13.8 in walkway) | Planning zone size (L × W) |
|---|---|---|---|---|
| Sitting Hyperbaric Chamber HS050 | 1.04 m² / 11.2 sq ft | 1.38 m² / 14.8 sq ft | 2.47 m² / 26.6 sq ft | 2470 × 1000 mm 8 ft 1.2 in × 3 ft 3.4 in |
| Sitting & Lying Hyperbaric Chamber HC050 | 1.30 m² / 14.0 sq ft | 1.64 m² / 17.6 sq ft | 2.87 m² / 30.9 sq ft | 2870 × 1000 mm 9 ft 5.0 in × 3 ft 3.4 in |
| Lying Hyperbaric Chamber HL050 (M) | 1.50 m² / 16.1 sq ft | 1.89 m² / 20.3 sq ft | 3.16 m² / 34.0 sq ft | 2870 × 1100 mm 9 ft 5.0 in × 3 ft 7.3 in |
| Lying Hyperbaric Chamber HL050 (L) | 1.80 m² / 19.4 sq ft | 2.22 m² / 23.9 sq ft | 3.59 m² / 38.6 sq ft | 3120 × 1150 mm 10 ft 2.8 in × 3 ft 9.3 in |
Carton data for freight and handling per chamber set, from HEAOCEAN packing sheets:
| Configuration | Cartons | Net / gross weight | Longest carton | Carton volume |
|---|---|---|---|---|
| Sitting Chamber HS050 | 6 | 66.7 / 74.8 kg | 120 × 9 × 29 cm | 0.51 m³ |
| Sitting & Lying Chamber HC050 | 5 | 62.2 / 68.1 kg | 126 × 4 × 48 cm | 0.34 m³ |
| Sitting & Lying Chamber HC050 with optional chairs | 7 | 81.5 / 92.1 kg | 65 × 31 × 127 cm | 0.77 m³ |
| Lying Chamber HL050 (M) | 4 | 50.4 / 55.2 kg | 75 × 75 × 42 cm | 0.52 m³ |
Final packing, weights, and accessories are confirmed in the written quotation.
Yes. We regularly supply multiple units for commercial projects, including mixed configurations across different locations, with consolidated documentation and coordinated shipping.
We provide product specifications and dimensional details for architects, contractors, and interior designers, plus installation planning guidance for floor space, power, and ventilation.
Soft shell is lighter, more portable, and lower cost, usually the better choice for studios and spaces that may relocate. Hard shell offers a more durable structure and stronger presence for high-traffic or flagship sites. The soft vs hard shell guide covers the trade-offs.
Standard soft-shell models run at about 1.3 ATA. A 1.5 ATA working pressure is a built-to-order custom configuration, confirmed in writing before production.
Yes. Branding, colors, and finish can be customized to match your interior and identity. See the OEM and private label page.
We provide appropriate HS codes and complete shipping documentation, and support FOB and DDP delivery terms.
Our factory operates under a quality management system certified to ISO 13485:2016. The certificate applies to the management system, not to the products as medical devices. Our chambers are supplied as wellness products, not medical devices, and no medical claims are made.
It depends on session length, booking volume, and how many rooms you have. Tell us your plan and we will help you size the first order. Mixed configurations are possible if you want to offer different postures.
Yes. We regularly supply multiple units for commercial projects, with consolidated documentation and coordinated shipping.
Share your project details and we will recommend a configuration and prepare a project quotation.
Tell us about your space and expected use. We will recommend a model and quantity.
